Smart energy storage cabinet
integrated solution provider
| DC parameters | ||||
| HJ-ESS-100A | HJ-ESS-115A | HJ-ESS-215A | HJ-ESS-372L | |
| Battery Type | Lithium Iron Phosphate | |||
| Cell capacity | 3.2V/280Ah | 3.2V/150Ah | 3.2V/280Ah | 3.2V/280Ah |
| System battery configuration | 1P112S | 1P240S | 1P240S | 1P416S |
| Battery rated capacity | 100KWh | 115kWh | 215kWh | 372kWh |
| Battery voltage range | DC280-403V | DC636-876V | DC636-876V | DC1165-1500V |
| Charge and discharge rate | 0.5C | 0.5C | 0.5C | 0.5C |
| Discharge depth | 80% | |||
| Battery cooling method | Forced Air Cooling | air cooling | air cooling | liquid cooling |
| AC parameters | ||||
| AC side rated power | 50KW | 100KW | 150KW | |
| Maximum power on AC side | 55KW | 110KW | 165KW | |
| Cable total harmonic distortion rate | <3% of rated power | |||
| AC side rated voltage | 380VAC | |||
| Communication access method | 3P+N+PE | |||
| Rated grid frequency | 50/60Hz | |||
| Power factor range | 0.98 | |||
| Off-grid operation | Support | |||
| System parameters | ||||
| size | 2000mm * 800mm * 900mm | 1600 * 1200 * 2000mm (reference) | 1600 * 1280 * 2200mm (reference) | 1400 * 1300 * 2350mm (reference) |
| Protection level | IP20 | IP55 | ||
| System communication protocol | Standard: Modbus | |||
| Temperature control method | Natural Heat Dissipation | Industrial grade temperature controlled air conditioner | Industrial grade temperature controlled air conditioner | Liquid cooling unit |
| fire protection plan | Aerosol | Aerosol, perfluorohexanone | ||
| Communication Interface | RS485, RJ45 | |||
